CAGIVA MITO SP525 Technical Specs SP 525

See if your lucky and find any Cagiva mito SP125 for sale on Ebay UK here

NOW ive never owned one hence why theres not much information on them here , and i did not like them to begin with but like most things that change the more you see them they get better and better , im looking to get one of these very soon .

heres some specs ill add more when i get one and eventually get the spanners on it , hopefully not too different to evos, but we'll see.

Displacement 124.60 Ccm (7.60 Cubic Inches)

Engine Type Single Cylinder, Two-Stroke

Power 12.07 HP (8.8 KW)) @ 9000 RPM

Torque 11.00 Nm (1.1 Kgf-M Or 8.1 Ft.Lbs) @ 7500 RPM

Bore X Stroke 50.0 X 50.6 Mm (2.0 X 2.0 Inches)

Fuel System Carburettor. Dell Ortho

Ignition C.D.I. With Variable Spark Advance

Lubrication System Automatic Mixer

Cooling System Liquid

Gearbox 6-Speed

Final Drive Chain

Clutch Multiplate In Oil Bath

Frame Type Aluminium Profi Frame

Rake (Fork Angle) 65.0°

Trail 98 Mm (3.9 Inches)

Front Suspension Upside-Down Marzocchi Forks.

Rear Suspension Adjustable Rebound And Damping Shock Absorber.

Front Tyre Dimensions 110/70-ZR17

Rear Tyre Dimensions 150/60-ZR17

Front Brakes Double Disc. 4-Piston

Front Brakes Diameter 320 Mm (12.6 Inches)

Rear Brakes Single Disc. 2-Piston

Rear Brakes Diameter 230 Mm (9.1 Inches)

Wheels 6-Spoke Black Wheels

Dry Weight 129.0 Kg (284.4 Pounds)

Power/Weight Ratio 0.0936 HP/Kg

Seat Height 760 Mm (29.9 Inches) If Adjustable, Lowest Setting.

Overall Length 1,980 Mm (78.0 Inches)

Ground Clearance 150 Mm (5.9 Inches)

Wheelbase 1,375 Mm (54.1 Inches)

Fuel Capacity 14.00 Litres (3.70 Gallons)

Oil Capacity 0.80 Litres (0.05 Quarts)

Starter Electric

Instruments Analogue

Electrical 12 V

Color Options Red, White, Red/Gray, Black


In 2012, production of new Mitos was suspended. Increasingly stringent environmental emission requirements and the concentration of resources on MV Agusta's F3 were cited as reasons. The last few Mito SP525s produced were white in colour, and personally signed by MV Agusta CEO Giovanni Castiglioni, thus ended the legacy of the Mito.
